5846/5847 High Performance 20W LED Fog Lights

LENGTH OF WARRANTY:

• 2 Year Warranty

FITMENT INFORMATION:

• 5846 fits all Jeep JK models, Jeep JL/JT Non-Sport models, and JL/JT Sport with the Max Tow Package ONLY.

• 5847 is designed for all Jeep JL/JT Sport models.

If your fog lights don't seem to fit correctly, here's what to do:

1. Please let us know the Year, Make, and Model of your vehicle.

2. Share photos of the back of your stock light and compare them to our website's information, especially the mounting tabs layout.

If you find that you've purchased the wrong bracket and need to exchange it:

• If you have 5846 and require 5847 (or vice-versa), you can remove the bracket from your fog light. We can then proceed with an exchange. Our standard Return Merchandise Authorization (RMA) process applies, but kindly note that shipping costs for exchanges are your responsibility.

For reference, the bracket part numbers are as follows:

• 5846 Bracket: *2722538-5846

• 5847 Bracket: *2722538-5847

If you have a factory bumper and encounter issues with the adjustment screws aligning with the bumper, you have a couple of options:

1. If the brackets on the lights align with the bumper without any problems, you can adjust the light's position before installation.

2. Alternatively, you can choose to drill a hole on the bumper to match up with the adjustment screw on the 5846 lights for a proper fit.

WIRING INFORMATION:

• Note: DRL wire cannot be used as a power source. Tapping into park lights will give manual control over LED accessory during daytime driving. LED accessory will turn on automatically in night mode when switch is set to AUTO. For full automatic control over the LED accessory, use fuse F52 in the engine compartment fuse panel.

• JK Installation Guide- https://cdn.shopify.com/s/files/1/1766/0599/files/5846_5847_Install.pdf?1362

• JK Installation Guide- https://vimeo.com/388261336




Wiring Suggestion- this would normally pair with the headlights, which wiring suggestions below include:

White & Amber- Legal Colors

Parking Light & Ignition (fuse)- https://www.youtube.com/watch?v=HpyD7IoGEC0&feature=emb_title

• Non-Legal Colors

  Toggle Switch- https://vimeo.com/297160645

  Single Color Remote 1701 or Flush Mount Switch https://vimeo.com/442422168

  Color Shift Controller- https://vimeo.com/247867593

TROUBLESHOOTING:

Issue: Entire LED Out (No Light Output Inside the Fog Light)

1. Start by swapping the harness from the side with the issue to the side that's functioning properly.

2. Ensure that the Plug & Play (P&P) harness is correctly and securely plugged in. Sometimes, these can be plugged in backward at the 9005 plug side.

• If the issue transfers with the harness to the other side: We will replace the harness at no cost; however, the customer will be responsible for the shipping fees.

• If the issue remains on the same side: Please request a Return Merchandise Authorization (RMA) to initiate the replacement process.

Issue: Water in the Fog Light

• If you notice light water spots inside your fog light, please contact customer service.

• If you have excess water inside the fog light, causing pooling please contact customer service.

Issue: Individual LEDs Out

If you encounter individual LEDs that are not functioning, please contact customer service.
